ZCU111 Board User Guide 62
UG1271 (v1.1) August 6, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
SFP_MOD_DETECT Test point J39
High = Module not present
Low = Module present
SFP_RS0 PU R289/PD R291
PU R289 = Full RX bandwidth
PD R291 = Reduced RX bandwidth
SFP_RS1 PU R290/PD R292
PU R290 = Full TX bandwidth
PD R292 = Reduced TX bandwidth
SFP_LOS Test point J41
High = Loss of receiver signal
Low = Normal operation
SFP3 J42
(1)(2)
SFP_TX_FAULT Test point J43
High = Fault
Low = Normal operation
SFP_TX_DISABLE Jumper J44
Off = SFP disabled
On = SFP enabled
SFP_MOD_DETECT Test point J45
High = Module not present
Low = Module present
SFP_RS0 PU R294/PD R300
PU R294 = Full RX bandwidth
PD R300 = Reduced RX bandwidth
SFP_RS1 PU R295/PD R301
PU R295 = Full TX bandwidth
PD R301 = Reduced TX bandwidth
SFP_LOS Test point J46
High = Loss of receiver signal
Low = Normal operation
Notes:
1. The RS0/RS1 PU/PD resistors are not populated.There are pull-down resistors built into the SFP28 modules that
select the lower bandwidth mode of the module.
2. BW selection is also available via I2C control. For this and additional information about the SFP28 module, see
SFF-8402 and SFF-8432 at the specification website [Ref 28].
Table 3-21: SFP28 Control and Status Board Test Points (Cont’d)
SFP28 Control/
Status Signal
Board Connection
