ZCU111 Board User Guide 63
UG1271 (v1.1) August 6, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Tab l e 3- 2 2 lists the SFP28 module connections to the Zynq UltraScale+ RFSoC U1.
For additional information about the small form factor pluggable SFP28 module, see the
SFF-8402 and SFF-8432 specifications at the SNIA Technology Affiliates website [Ref 28].
Table 3-22: SFP28 RFSoC Connections
XCZU28DR Pin
(U1)
Schematic Net
Name
I/O Standard SFP+ Pin SFP+ Pin Name
SFP0 J27
Y35 SFP0_TX_P
(1)
18 TD_P
Y36 SFP0_TX_N
(1)
19 TD_N
AA38 SFP0_RX_P
(1)
13 RD_P
AA39 SFP0_RX_N
(1)
12 RD_N
G12 SFP0_TX_DISABLE_B LVCMOS12 3 TX_DISABLE
SFP1 J32
V35 SFP1_TX_P
(1)
18 TD_P
V36 SFP1_TX_N
(1)
19 TD_N
W38 SFP1_RX_P
(1)
13 RD_P
W39 SFP1_RX_N
(1)
12 RD_N
G10 SFP0_TX_DISABLE_B LVCMOS12 3 TX_DISABLE
SFP2 J37
T35 SFP2_TX_P
(1)
18 TD_P
T36 SFP2_TX_N
(1)
19 TD_N
U38 SFP2_RX_P
(1)
13 RD_P
U39 SFP2_RX_N
(1)
12 RD_N
K12 SFP0_TX_DISABLE_B LVCMOS12 3 TX_DISABLE
SFP3 J42
R33 SFP3_TX_P
(1)
18 TD_P
R34 SFP3_TX_N
(1)
19 TD_N
R38 SFP3_RX_P
(1)
13 RD_P
R39 SFP3_RX_N
(1)
12 RD_N
J7 SFP0_TX_DISABLE_B LVCMOS12 3 TX_DISABLE
Notes:
1. Bank 128 GTY connections, I/O standards not applicable.
