Xilinx Zynq UltraScale+ ZCU208 User Manual

Chapter 2
Board Setup and Configuration
Standard ESD Measures
CAUTION! ESD can damage electronic components when they are improperly handled, and can result in total
or intermient failures. Always follow ESD-prevenon procedures when removing and replacing components.
To prevent ESD damage:
• Aach a wrist strap to an unpainted metal surface of your hardware to prevent electrostac
discharge from damaging your hardware.
• When you are using a wrist strap, follow all electrical safety procedures. A wrist strap is for
stac control. It does not increase or decrease your risk of receiving electric shock when you
are using or working on electrical equipment.
• If you do not have a wrist strap, before you remove the product from ESD packaging and
installing or replacing hardware, touch an unpainted metal surface of the system for a
minimum of ve seconds.
• Do not remove the device from the anstac bag unl you are ready to install the device in
the system.
• With the device sll in its anstac bag, touch it to the metal frame of the system.
• Grasp cards and boards by the edges. Avoid touching the components and gold connectors on
the adapter.
• If you need to lay the device down while it is out of the anstac bag, lay it on the anstac
bag. Before you pick it up again, touch the anstac bag and the metal frame of the system at
the same me.
• Handle the devices carefully to prevent permanent damage.
Board Component Location
The following gure shows the ZCU208 board component locaons. Each numbered component
shown in the gure is keyed to Table 2.
Chapter 2: Board Setup and Configuration
UG1410 (v1.0) July 8, 2020 www.xilinx.com
ZCU208 Board User Guide 11
Send Feedback
