Appendix B
Xilinx Design Constraints
Overview
The Xilinx design constraints (XDC) le template for the ZCU208 board provides for designs
targeng the ZCU208 evaluaon board. Net names in the constraints listed correlate with net
names on the latest ZCU208 evaluaon board schemac. Idenfy the appropriate pins and
replace the net names with net names in the user RTL. See the Vivado Design Suite User Guide:
Using Constraints (UG903) for more informaon.
The HSPC FMCP connector J28 is connected to Zynq
®
UltraScale+™ RFSoC U1 banks powered
by the variable voltage VADJ_FMC. The FMC bank I/O standards must be uniquely dened by
each customer because dierent FMC cards implement dierent circuitry.
IMPORTANT!
See the ZCU208 board documentaon ("Board Files" check box) for the XDC le.
