Chapter 1
Introduction
Overview
The ZCU208 is an evaluaon board featuring the ZU48DR Zynq
®
UltraScale+™ RFSoC Gen 3
device. This board enables the evaluaon of applicaons requiring sub-6 GHz bands for radio,
mmWave, and full L-band and S-Band in phased array radar. The ZCU208 board is equipped with
all the common board-level features needed for design development, such as DDR4 memory,
networking interfaces, an FMC+ expansion port, as well as access to the RFMC 2.0 interface.
Document Audience and Scope
The purpose of this guide is to familiarize system architects, soware developers, and hardware
designers with the ZCU208 evaluaon board. The ZCU208 board enables the demonstraon,
evaluaon, and development of numerous applicaons.
Additional Resources
See Appendix D: Addional Resources and Legal Noces for references to documents, les, and
resources relevant to the ZCU208 evaluaon board.
Chapter 1: Introduction
UG1410 (v1.0) July 8, 2020 www.xilinx.com
ZCU208 Board User Guide 5
