Chapter 3
Board Component Descriptions
Overview
This chapter provides a descripon of the board’s components and features. Table 2 idenes
the components and references the respecve schemac page numbers. Component locaons
are shown in Figure 2.
Component Descriptions
Zynq UltraScale+ RFSoC XCZU48DR
[Figure 2, callout 1]
The ZCU208 board is populated with the Zynq
®
UltraScale+™ RFSoC XCZU48DR-2FSVG1517,
which combines a powerful processing system (PS) and user-programmable logic (PL) in the same
device. The processing system in a Zynq
®
UltraScale+™ RFSoC features the Arm
®
agship
Cortex™- A53 64-bit quad-core processor and Cortex™-R5F dual-core real-me processor.
The V
CCINT
supplies are user adjustable through the PMBus with the voltage ranges to support
whichever Zynq UltraScale+ RFSoC speed grade is on the evaluaon board. See the Zynq
UltraScale+ RFSoC Data Sheet: DC and AC Switching Characteriscs (DS926) for more informaon.
Top-level Block Diagram
The following gure shows the top-level block diagram for the Zynq UltraScale+ RFSoC.
Chapter 3: Board Component Descriptions
UG1410 (v1.0) July 8, 2020 www.xilinx.com
ZCU208 Board User Guide 21
Send Feedback
