Xilinx Zynq UltraScale+ ZCU208 User Manual

Table 1: Zynq UltraScale+ RFSoC ZU48DR Features and Resources (cont'd)
Feature Resource Count
UltraRAM blocks 80 (22.5 Mb)
DSP slices 4,272
PCIe
®
Gen3 x16 / Gen4 x8 / CCIX (3) 2
150G Interlaken 1
100G Ethernet with RS-FEC 2
Board Specifications
Dimensions
Height: 12.225 inches (31.05 cm)
Width: 10.675 inches (27.11 cm)
Thickness: 0.119 inches (0.302 cm)
Note: A 3D model of this board is not available.
See the ZCU208 Evaluaon Board website for the XDC lisng and board schemacs.
Environmental
• Temperature:
Operang: 0°C to +45°C
Storage: –25°C to +60°C
• Humidity: 10% to 90% non-condensing
Operating Voltage
+12 V
DC
Chapter 1: Introduction
UG1410 (v1.0) July 8, 2020 www.xilinx.com
ZCU208 Board User Guide 10
Send Feedback
