Figure 32: TM40-0157-00 Landing Pad
070± 0.025
AD
O .085[2.150]
O .012+001[0:]
45
o
TYP
.031[0.790]
.016[0.411]
.024[0.600]
.024[0.600]
.078[1.986]
.530± 0.013
X23659-041420
SMAs: Carlisle Compression – Mount SMA, TMB-V5F2-1L1
Appendix C: HW-XM650/655 Balun Daughter Cards for Gen 3 RFSoC EVM
UG1410 (v1.0) July 8, 2020 www.xilinx.com
ZCU208 Board User Guide 81
Send Feedback
