Xinje DF3E Series User Manual

156
Parameter
Function
Unit
Default
value
Range
Effective
Suitable
mode
Reference
chapter
P5-31.0~1
/ZCLAMP: zero position
clamping
-
00
0~ff
√
3|7
4.4.1.2
P5-31.2
SI terminal filtering time
ms
0
0~f
√
3|7
4.8.4.1
P5-32.0~1
/INHIBIT: Instruction pulse
prohibition
-
00
0~ff
√
5|6|7
4.3.1.4
P5-32.2
SI terminal filtering time
ms
0
0~f
√
5|6|7
4.8.4.1
P5-34.0~1
/CLR: pulse offset clear
-
00
0~ff
√
5|6
4.3.1.5
P5-34.2
SI terminal filtering time
ms
0
0~f
√
5|6
4.8.4.1
P5-35.0~1
/CHGSTP: internal position
mode change step signal
-
00
0~ff
√
5
4.3.3
P5-35.2
SI terminal filtering time
ms
0
0~f
√
5
4.8.4.1
P5-36.0~1
/I-SEL: inertia ratio switching
-
00
0~ff
√
1|3|5|6|7
5.6.7
P5-36.2
SI terminal filtering time
ms
0
0~f
√
1|3|5|6|7
4.8.4.1
P5-37
/COIN_HD: Location
Completion Maintenance
00: No output to terminal
01: Output positive signal
from SO1 terminal
02: Output positive signal
from SO2 terminal
03: Output positive signal
from SO3 terminal
11: Output reverse signal from
SO1 terminal
12: Output reverse signal from
SO2 terminal.
13: Output reverse Signal from
SO3 terminal
-
0000
0~ffff
√
5|6
4.3.1.2
P5-38
/COIN: positioning
completion
-
0001
0~ffff
√
5|6
4.3.1.2
P5-39
/V-CMP: same speed detection
-
0000
0~ffff
√
3|7
4.8.5.3
P5-40
/TGON: rotation detection
-
0000
0~ffff
√
1|3|5|6|7
4.8.5.2
P5-41
/S-RDY: ready
-
0000
0~ffff
√
1|3|5|6|7
4.8.5.1
P5-42
/CLT: torque limit
-
0000
0~ffff
√
1|3|5|6|7
4.8.2
P5-43
/VLT: speed limit detection
-
0000
0~ffff
√
1
4.5.1.3
P5-44
/BK: brake locking
-
0000
0~ffff
○
1|3|5|6|7
4.2.5
P5-45
/WARN: warning
-
0000
0~ffff
√
1|3|5|6|7
4.12.2
P5-46
/NEAR: near
-
0000
0~ffff
√
5|6
4.3.7
P5-47
/ALM: alarm
-
0002
0~ffff
√
1|3|5|6|7
4.2.6
P5-48
/Z: encoder Z phase signal
output
-
0000
0~ffff
√
1|3|5|6|7
4.12.5
P5-50
/MRUN: internal position
mode motion starting signal
-
0000
0~ffff
√
5
4.3.3.6
P5-51
/V-RDY: speed reached
-
0000
0~ffff
√
3|7
4.4.1.3
P5-52
/USER1: user-defined output 1
-
0000
0~ffff
√
1|3|5|6|7
4.8.5.7
P5-53
/USER2: user-defined output 2
-
0000
0~ffff
√
1|3|5|6|7
4.8.5.7
P5-57.0~1
/PREFA: intenral position
selection signal A
-
00
0~ff
√
5
4.3.3.1
P5-57.2
SI terminal filtering time
ms
0
0~f
√
5
4.8.4.1
P5-58.0~1
/PREFB: intenral position
selection signal B
-
00
0~ff
√
5
4.3.3.1
P5-58.2
SI terminal filtering time
ms
0
0~f
√
5
4.8.4.1
P5-59.0~1
/PREFC: internal position
-
00
0~ff
√
5
4.3.3.1
