Xinje DS5B Series User Manual

1-2-2.Model name
MS5S – 80 ST E – C S 02430 B Z - 2 0P7 – S01
Name
Rated power
(KW)
0P2 0.2
0P4 0.4
0P7 0.75
Name Voltage level
2 220V
4 380V
Name Power-off brake
- -
Z with
Name Shaft
A No key
B With key
Name inertia
MS5S Low inertia
MS5G Middle inertia
MS5H High inertia
Name Base no.
60 60 base
80 80 base
Name Product name
ST Sine driven motor
Name Encoder type
C Magnetic
T Optical
Name Rated torque (N·m)
00630 0.637
01330 1.3
Rated speed (rpm)
3000
3000
Name Encoder precision
S Single rotate 17 bits
M Multi-rotate 17 bits
U Single rotate 23 bits
L Multi-rotate 23 bits
Name Design no.
S01 standard
02430 2.39 3000
Name Oil seal
- -
E with oil seal
1-3.Cable
1-3-1.Cable configuration
Servo drive model
Encoder cable
Motor cable
Brake cable
DS5B-20P1-PTA
DS5B-20P2-PTA
DS5B-20P4-PTA
DS5B-20P7-PTA
CP-DP-M(B)-length
CM-P07-length
