Output signal wirin
g diagram
Optocoupler type
Relay type
Servo drive
upper device
COM
SO
X3
COM
0
V
+24
V
Servo drive
upper device
+24
V
0
V
COM
X3
SO
COM
Note:
max
lo
ad
current
400mA
(if
control
the
brake
motor
by
SO
signal,
please
confirm
the
brake
current,
if
it
is
larger
than
400mA,
please
use
intermediate
relay).
7
50w
and
above
power motor is recommended to use intermediate relay
.
3-3. Comm
unication port
RS
-
232
communication
Connect to PC for debugging.
(5
-pin port)
Pin no.
Name
Explanation
1
TXD
RS232 send
2
R
XD
RS232 receive
3
GND
RS232 ground
Note: please use the cable supplied by XINJE Company
RS
-
485
communication
37
39
