2-4.Servo drive dimension
Unit: mm
DS5B-20P1-PTA/DS5B-20P2-PTA/DS5B-20P4-PTA/DS5B-20P7-PTA
70.0
59.0
186.0
166.0
DS5B-21P5-PTA/DS5B-22P3-PTA/DS5B-22P6-PTA
