◆ The installation process is not allowed
to impact the shaft extension, otherwise
the internal encoder will be broken.
◆ When a pulley is mounted on a servo motor shaft with a keyway,
screw holes are used at the end of the shaft. To install the pulley, first
insert the double-headed nail into the screw hole of the shaft, use the
washer on the surface of the coupling end and gradually lock the nut
into the pulley.
◆ For the servo motor shaft with a keyway, the shaft end screw hole is
used for installation. For a shaft without a keyway, a frictional coupling
or similar method is used.
◆ When removing the pulley, a pulley stripper is used to prevent the
bearing from being strongly impacted by the load.
◆ To ensure safety, a protective cover or similar device, such as a
pulley mounted on a shaft, is installed in the rotating area.
