Xinje DS5B Series User Manual

P1-02
Position loop
gain
In the absence of noise and vibration, increasing this
parameter can speed up the positioning time
P2-00.0
Disturbance
observer switch
0-OFF 1-ON
P2-00.2
Dead zone
compensation
switch
0-ON 1-OFF
Turn off the dead zone can reduce the sound
P2-01.0
Auto-tuning
switch
0-auto-tuning 1-adaptive
P2-35
Torque filter
time constant
increase this value can reduce the noise, but the velocity
fluctuation will become larger and vibration will easily
occur.
If this value is reduced, the noise will increase, but the
velocity fluctuation will decrease.
The greater the load inertia, the greater the value
P2-41
Disturbance
observer gain
Set to 85 in auto-tuning mode, be effective after P2-00.0
disturbance observer switch is ON
P2-47.0
Model loop gain
switch
0-OFF 1-ON
P2-49
Model loop gain
Be effective after P2-47.0 model loop gain switch is ON
When the value is increased, the rigidity level will be
improved and the position curve following features will be
improved, but it is easy to overshoot.
decreasing this value can reduce the overshoot, but the
position curve becomes less traceable
P2-69.0
First notch wave
switch
0-OFF 1-ON
P2-69.1
second notch
0-OFF 1-ON
