Xinje DS5E Series User Manual

122
02
0
E-020
Parameter loading error
1
E-021
Parameter range beyond limit
○
2
E-022
Parameter conflict
√
○
3
E-023
Sampling channel setting error
4
E-024
parameter lost
√
○
5
E-025
Erase FLASH error
√
○
6
E-026
Initialization FLASH error
√
○
03
0
E-030
Bus voltage U0-05 is higher than
the actual preset threshold, and
lasts for P0-83 setting time to
alarm.
220V Power Supply Machine
(U0-05≥390V)
380V Power Supply Machine
(U0-05≥50V)
There are two
possibilities of
bus
undervoltage: (1)
the low voltage
of power grid,
(2) the
undervoltage of
bus voltage
caused by power
failure of driver.
The former can
be remembered,
while the latter
can not.
○
Servo OFF
04
0
E-040
Bus voltage U0-05 is lower than
the actual preset threshold.
220V power supply machine
(U0-05 ≤ 150V)
380V power supply machine
(U0-05 ≤ 350V)
√
○
1
E-041
Driver power down
○
3
E-043
Bus Voltage Charging Failure
√
Servo OFF
06
0
E-060
Module temperature is too high
(Module temperature U-06 ≥ 90℃
alarm, U-06 ≥ 70℃ Warning)
√
○
08
0
E-080
Overspeed (actual speed ≥
P3-21/P3-22)
The maximum forward speed is
P3-21 and the maximum reverse
speed is P3-22.
√
○
09
2
E-092
Analog Tref Zero-Calibration
Over limit
√
○
3
E-093
Analog Vref Zero-Calibration
Over limit
√
○
10
0
E-100
Excessive position deviation
√
○
11
0
E-110
External UVW Short Circuit
Discovered in Self-Inspection
√
○
Servo OFF
12
0
E-120
Abnormal Current Sensor
√
○
Servo OFF
1
E-121
Abnormal Zero Value of U Phase
Current Sampling
√
○
Servo OFF
2
E-122
Abnormal Zero Value of V Phase
Current Sampling
√
○
Servo OFF
13
0
E-150
Power cable disconnection
√
○
Servo OFF
16
1
E-161
Driver thermal power overload
√
○
5
E-165
Anti-blocking alarm
Judging that the current motor
output torque is greater than
P3-28/P3-29 (internal
forward/reverse torque limit), and
the time reaches P0-74 (unit ms),
√
○
