86
5.12.7 I/O signal distribution
Input signal distribution
n. 0
Distribute input
terminal no.
0: NO signal
1: NC signal
No meaning
Basic filter time
Not distribute to terminal input
Input always open signal from SIx
Set the signal to be always valid
Input always close signal from SIx
Note: The basic filtering time refers to chapter 5.12.8.
Default setting of input terminal
Output signal distribution
n. 0
Distribute output
terminal no.
0: NO signal
1: NC signal
No meaning
No meaning
Not distribute to terminal input
Output always open signal from
SOx
Set the signal to be always valid
output always close signal from
SOx
Default setting of output terminal
5.12.8 Input SI filter time
SI input filtering time is determined by IO parameter value and P5-18. Examples are as follows:
Pulse deviation clear set to SI1 terminal, and 30ms Filtering Time
The parameters are set as follows:
P5-34=n. 0 3 0 1
P5-34.0
P5-34.2
P5-34.0=1 input terminal is SI1
P5-34.2=3 basic filtering time is 3ms
P5-18=10 filtering time multiple is 10
So the total filtering time is P5-34.2 * P5-18=3ms*10=30ms
