34
4.4 Group F Auxiliary Functional Parameters
4.4.1 Group F0
Panel inertia identification
Resume to default settings
Panel external instruction
auto-tuning
Clear the position offset
Panel internal instruction
auto-tuning
Clear up historical alarm records
Panel vibration suppression 1
Panel vibration suppression 2
1. Alarm clear（F0-00）
Setting F0-00=1 can reset the alarm status. When an alarm occurs, please first eliminate the cause of
the alarm, and then clear up the alarm.
2. Resume to default setting（F0-01）
Set F0-01=1 when enabler is shut down, press ENTER to resume to default settings, no need to cut
power.
3. Clear the position offset（F0-02）
Set F0-02=1 to clear the offset.
4. Clear up historical alarm records（F0-04）
Set F0-04=1 can clear up historical alarm records from U1-14 to U1-53.
5. Panel inertia identification （F0-07）
Refer to panel inertia identification operation steps chapter 6.3.4.
6. Panel external instruction auto-tuning（F0-08）
Refer to external instruction auto-tuning chapter 6.5.5.
7. Panel internal instruction auto-tuning（F0-09）
Refer to internal instruction auto-tuning chapter 6.5.4.
8. Panel vibration suppression（F0-10, F0-11）
Refer to vibration suppression chapter 6.7.4.
4.4.2 Group F1
Tref（torque analog）zero-correction
(not support)
Current Sampling Zero-correction
Reset circles of absolute encoder
Vref (speed analog)
zero-correction (not support)
1. Test run（F1-01）
Before entering the test run mode, please confirm that the motor shaft is not connected to the
machine!
