2.2 Servo motor installation
MS series servomotors can be installed either horizontally or vertically. The service life of the
servomotor can be shortened or unexpected problems might occur if it is installed incorrectly or in an
inappropriate location. Follow these installation instructions carefully.
1． The end of the motor shaft is coated with antirust. Before installing, carefully remove all of the
paint using a cloth moistened with paint thinner.
2． Avoid getting thinner on other parts of the servo motor.
2.2.1 Installation environment
Do not use this product near corrosive and flammable gas environments such as hydrogen sulfide,
chlorine, ammonia, sulfur, chlorinated gas, acid, alkali, salt, etc.
In places with grinding fluid, oil mist, iron powder, cutting, etc., please choose motor with oil seal.
A place away from heat sources such as stoves;
Do not use motor in enclosed environment. Closed environment will lead to high temperature and
shorten service life of motor.
2.2.2 Environment condition
When used in places with water droplets or oil droplets, the protection effect can be achieved through
the treatment of motors. However, in order to seal the through part of the shaft, please specify the
motor with oil seal. Connectors should be installed downward.
MS series servo motors are for indoor use. Please use them under the following installation conditions:
20%~90%RH (no condensation)
-20%~90%RH (no condensation)
Through part of the shaft
