Xinje DS5E Series User Manual

124
error
self-checking
parameters, if there are repeated
problems, please contact the
agent or manufacturer.
1
E-021
Parameter range
beyond limit
Setting values are not
within the prescribed
range
Check parameters and reset them
2
E-022
Parameter conflict
Conflict of TREF or
VREF Function
Settings
P0-01=4, P3-00 set to 1 will
alarm
3
E-023
Sampling channel
setting error
Error setting of custom
output trigger channel
or data monitoring
channel
Check that the settings are correct
4
E-024
parameter lost
Low voltage of power
grid
(1) If it is single-phase 220V
power supply, please connect L1
and L3.
(2) show E-024 immediately after
power failure
(3) Resetting parameters
5
E-025
Erase FLASH
error
Abnormal parameter
preservation during
power failure
please contact the agent or the
manufacturer
6
E-026
Initialization FLASH
error
Power supply
instability of FLASH
chip
please contact the agent or the
manufacturer
03
0
E-030
Bus voltage U0-05
is higher than the
actual preset
threshold, and
lasts for P0-83
setting time to
alarm.
220V Power
Supply Machine
(U0-05≥390V)
380V Power
Supply Machine
(U0-05≥50V)
High voltage of power
grid
Check the fluctuation of power
grid, 220V driver normal voltage
range 200V ~ 240V, 380V driver
normal voltage range 360V ~
420V. If the voltage fluctuation is
large, it is recommended to use
the correct voltage source and
regulator.
Excessive load
moment of inertia
(insufficient
regeneration capacity)
(1) connect external regenerative
resistor, (220V: bus voltage
U0-05 = 380 discharge starts,
U-05 = 350 discharge ends;
380V: U-05 = 700 discharge
starts, U-05 = 660 discharge
ends;)
(2) Increasing Acceleration and
Deceleration Time
(3) Reducing load inertia
(4) Reduce start-stop frequency
(5) Replacement of larger power
drivers and motors
Brake resistance
damage or excessive
resistance value
Check the regenerative resistor
and replace the external resistor
with the appropriate resistance
value. See chapter 1.4.1 for the
selection of the external resistor.
Acceleration and
deceleration time is
too short
Extending Acceleration and
Deceleration Time
Hardware Fault of
Driver Internal
Sampling Circuit
The AC gear of the multimeter
measures the input value of the
servo LN (R/S/T), which is 220V
± 10% of the normal value. If the
power supply voltage is more
than 220V+10% (380V+10%),
