Xinje DS5E Series User Manual

127
be operated on an empty shaft to
eliminate the load problem.
High-speed
start-stop
instantaneous alarm
Increasing Acceleration and
Deceleration Time
Encoder problem
(1) Check the encoder cable or
change a new one
(2) Set the servo driver to BB state
and the driver to U-10. Rotate the
motor shaft slowly by hand to see if
the value of U-10 changes
normally, increasing in one
direction and decreasing in one
direction (0-9999 cycle display).
12
0
E-120
Abnormal Current
Sensor
Current Sensor
Damage or External
Interference too
serious
Check whether grounding is normal
or not. If alarm cannot be ruled out,
please contact the agent or
manufacturer.
1
E-121
Abnormal Zero
Value of U Phase
Current Sampling
Current Sensor
Damage or External
Interference too
serious
Check whether grounding is normal
or not. If alarm cannot be ruled out,
please contact the agent or
manufacturer.
2
E-122
Abnormal Zero
Value of V Phase
Current Sampling
Current Sensor
Damage or External
Interference too
serious
Check whether grounding is normal
or not. If alarm cannot be ruled out,
please contact the agent or
manufacturer.
13
0
E-150
Power cable
disconnection
Any phase in UVW
of driver, cable or
motor broken
Disconnect the power supply of the
driver and check the connection of
the power cable. It is suggested that
the multimeter be used to test the
condition. After eliminating the
errors, the driver should be
re-energized.
16
1
E-161
Driver thermal
power overload
Not match the
motor code
Check if the driver P0-33 is
identical with the motor code of the
motor label (the number after
MOTOR CODE), if not, please
change to the same one, then power
on again.
Overload, the actual
operating torque
exceeds the rated
torque, and
continuous
operation for a long
time. (Monitor
U0-02 to check the
actual operating
torque. If the motor
is in normal
operation, it will
not jam or jitter. If
the U0-02 is longer
than 100, it will be
considered
improper selection
of the motor.)
Increase the capacity of drivers and
motors. Extend the acceleration and
deceleration time and reduce the
load. Monitor the U-00, whether it
is running over speed.
Mechanisms are
impacted, suddenly
weighted and
Eliminate mechanical distortion.
Reduce load
