Xinje DS5E Series

142
output speed
P5-09
Brake instruction
waiting time
ms
500
0~65535
○
1|2|3|4|5|6|7|10
5.2.5
P5-10
user-defined output 1
trigger condition
-
0
0~ffff
√
1|2|3|4|5|6|7|10
5.12.6
P5-11
Set a value that
compares with the
trigger condition of
custom output 1
Relating
to trigger
condition
0
-9999~9999
√
1|2|3|4|5|6|7|10
5.12.6
P5-12
Select custom output 1
mode
-
0
0~3
√
1|2|3|4|5|6|7|10
5.12.6
P5-13
Setting custom output
1 hysteresis
Relating
to trigger
condition
0
0~65535
√
1|2|3|4|5|6|7|10
5.12.6
P5-14
Custom Output 2
Trigger Condition
-
0
0~ffff
√
1|2|3|4|5|6|7|10
5.12.6
P5-15
Set a value that
compares with the
trigger condition of
custom output 2
Relating
to trigger
condition
0
-9999~9999
√
1|2|3|4|5|6|7|10
5.12.6
P5-16
Select custom output 2
mode
-
0
0~3
√
1|2|3|4|5|6|7|10
5.12.6
P5-17
Setting custom output
2 hysteresis
Relating
to trigger
condition
0
0~65535
√
1|2|3|4|5|6|7|10
5.12.6
P5-18
IO Filtering time
multiple
-
1
0~10000
√
1|2|3|4|5|6|7|10
5.12.8
P5-19
Z phase output
maintain time
ms
2
1~65535
√
1|2|3|4|5|6|7|10
5.12.5
P5-20.0~
1
/S-ON: servo signal
00: Set the signal to be
invalid all the time.
01: Input positive
signal from SI1
terminal.
02: Input positive
signal from SI2
terminal.
03: Input positive
signal from SI3
terminal.
04: Input positive
signal from SI4
terminal.
10: Set the signal to
always be "valid".
11: Inverse signal is
input from SI1
terminal.
12: Inverse signal is
input from SI2
terminal.
-
01
0~ff
√
1|2|3|4|5|6|7|10
5.2.1
