Parameter setting
Running mode: P0-01=6
Pulse command state: P0-10=2
Electronic gear ratio: P0-11=0 P0-12=0 P0-13=16384 P0-14=625
Forward torque limit: P3-28=150
Reverse torque limit: P3-29=150
Positioning finished width: P5-00=7
/S-ON: P5-20=0010
/CLR: P5-34=0001
/COIN: P5-38=0001
/CLT: P5-42=0002
Appendix 8. Model list
Power
(KW)
Inertia
level
Motor model
Suitable servo
driver
Voltage
level
Encoder cable
Power cable
0.1
Low
inertia
MS5S-40ST□-CS00330B-20P1-
S01
DS5E/L-20P1
-PTA
Single-
phase
220V
CP(T)-SP-M-
length
CM(T)-P07-M
-length
MS5S-40ST□-CM00330B-20P1-
S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
MS5S-40ST□-CS00330BZ-20P1
-S01
CP(T)-SP-M-l
ength
CM(T)-P07-M
-length
MS5S-40ST□-CM00330BZ-20P
1-S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
0.2
Low
inertia
MS5S-60ST□-CS00630B-20P2-
S01
DS5E/L-20P2
-PTA
CP(T)-SP-M-l
ength
CM(T)-P07-M
-length
MS5S-60ST□-CM00630B-20P2-
S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
MS5S-60ST□-CS00630BZ-20P2
-S01
CP(T)-SP-M-l
ength
CM(T)-P07-M
-length
MS5S-60ST□-CM00630BZ-20P
2-S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
High
inertia
MS5H-60ST□-CS0O630B-20P2
-S01
CP(T)-SP-M-l
ength
CM(T)-P07-M
-length
MS5H-60ST□-CM0O630B-20P
2-S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
MS5H-60ST□-CS00630BZ-20P
2-S01
CP(T)-SP-M-l
ength
CM(T)-P07-M
-length
MS5H-60ST□-CM00630BZ-20P
2-S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
0.4
Low
inertia
MS5S-60ST□-CS01330B-20P4-
S01
DS5E/L-20P4
-PTA
CP(T)-SP-M-l
ength
CM(T)-P07-M
-length
MS5S-60ST□-CM01330B-20P4-
S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
MS5S-60ST□-CS01330BZ-20P4
-S01
CP(T)-SP-M-l
ength
CM(T)-P07-M
-length
MS5S-60ST□-CM01330BZ-20P
4-S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
High
inertia
MS5H-60ST□-CS01330B-20P4-
S01
CP(T)-SP-M-l
ength
CM(T)-P07-M
-length
MS5H-60ST□-CM01330B-20P4
-S01
CP(T)-SP-BM
-length
CM(T)-P07-M
-length
