System Structure
As the controller, XC series PLC can connect with many types of peripheral equipments,
expansions etc. In this chapter, we mainly tells the peripheral devices, the connection principle of
CPU with expansions, installation, calculate the I/O points, input/output ID etc.
For the introduction of expansions, please refer to chapter 8;
3-1．System Structure
3-2．Peripheral Devices
3-3．Combination Principle
3-4．Expansion's ID assignment
3-5．Install the Products
