3 system structure
3-2．Peripheral Equipments
XC series PLC basic units can work with many kinds of peripheral equipments.
3-2-1．Program Software
Via program software, users can write to or upload program from PLC. Real time monitor PLC,
configure PLC etc; After installing XCPPro on your PC, use the program cable, via COM1 or
COM2 on PLC (CPU Units) to link PLC with XCPPro;
l Program Interface
※1：Please use the program cable offered by Xinje Electronic, or make the cable by yourself; the making method
is showing in Chapter 2-4

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
