Xinje XC3 Series User Manual

8 expansion devices
l Digital input/output quantity is in octal form;
l Input/output analog is in decimal form
l PLC main units can work with 7 expansions and one extra BD card. The expansion module
can be any type (analog or digital, temperature);
8-2．Digital Input/output Modules
Input/output expansions, I/O ranges 8~32、Input type、output type、input/output type、transistor
output、relay output etc;
The detailed models are listed below:
Model
Output
Input
Relay Output
Transistor
Output
I/O Nr.
Input Nr.
(DC24V)
Output
Nr.
(R,T)
XC-E8X - - 8 8 -
- XC-E8YR XC-E8YT 8 - 8
- XC-E8X8YR XC-E8X8YT 16 8 8
XC-E16X - - 16 16 -
- XC-E16YR XC-E16YT 16 - 16
- XC-E16X16YR XC-E16X16YT 32 16 16
XC-E32X - - 32 32 -
N
P
N
- XC-E32YR - 32 - 32
XC-E8PX - - 8 8 -
- XC-E8YR XC-E8YT 8 - 8
- XC-E8PX8YR XC-E8PX8YT 16 8 8
XC-E16PX - - 16 16 -
- XC-E16YR XC-E16YT 16 - 16
- XC-E16PX16YR XC-E16PX16YT 32 16 16
XC-E32PX - - 32 32 -
P
N
P
- XC-E32YR - 32 - 32
Model List 1

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
