Xinje XC3 Series User Manual

8 expansion devices
0V COM of power supply
8-3-5．XC-E2DA
Items Voltage Output Current Output
DC0～5V、0～10V
DC0～20mA、4～20mA
Analogue Output Range
External Load Resistor (2KΩ~1MΩ) External Load Resistor less than 500Ω
Digital Input Range
12 bits binary
Distinguish Ratio 1/4096(12Bit); the convert data is stored in PLC in form of Hex. (12Bit)
Integral Precision 0.8%
Convert Speed 3ms/CH
Power Supply DC24V±10%，100mA
0V
24V
VO0 VO1
C0 AO0 C1 AO1
CH NAME SIGNAL
AO0
Current analogue output
VO0
Voltage analogue output
CH0
C0
COM of CH0
Brief Introduction 1
Specification 2
Terminal Arrangement 3
l 2CH analogue output: voltage and current input selectable; Voltage input range is 0～5V、
0～10V selectable, current input range is 0～20mA、4～20mA selectable;
l 12 bits high precision analogue input;
l As the special module, 7pcs XC-E2DA can be connected to one XC series PLC main unit;

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
