Xinje XC3 Series User Manual

Relay output
Relay
output
Transistor
output
R/T Type
(DC24V)
(R，T)
- XCM-24T-E - - XCM-24T-C - 14 10
- XCM-32T-E - - XCM-32T-C - 18 14
N
P
N
- XCM-48T-E - - XCM-48T-C - 28 20
- XCM-24PT-E - - XCM-24PT-C - 14 10
- XCM-32PT-E - - XCM-32PT-C - 18 14
P
N
P
- XCM-48PT-E - - XCM-48PT-C - 28 20
※1：XC1 can also have special 20 I/O model
※2：XCM-48 is in developing
1-2-2．Expansion's name principle and module list
1：Series name XC
2：For Expansion E
3：Input points 8、16、32
4：For Input NPN Type: X
PNP Type: PX
5：Output points 8、16、32
6：For output YR：relay output
YT：transistor output
l I/O expansions list:
Model
Output
Input
relay output transistor output
I/O
Points
Input
points
(DC24V)
Output
points
(R, T)
XC-E8X - - 8 8 - N
P
- XC-E8YR XC-E8YT 8 - 8
I/O
Expansion
1
The I/O expansions' name principle:
XC
1 2 3 4
E
5 6

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
