Xinje XC3 Series User Manual

4 power supply specification and wiring method
4-2．AC Power DC Input Type
※1：Connect the power supply to L, N terminals
※2：24V、COM can supply 400mA/DC24V power supply. Do not give these two terminals power supply
※3： . terminals are blank terminals, please do not wire them or use them as middle relays
※4：Please connect the COM terminals on basic units and expansions together
1 Connection


Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
