Xinje XC3 Series User Manual

8 expansion devices
8-1．MODULES SUMMARY
Item Content
Using environment noncorrosive gas
Environmental Temperature 0 ~60℃ ℃
Stock temperature -20~70℃
Environmental Humidity 5~95%
Stock Humidity 5~95%
Installation Use M3 screws to fix or install on DIN46277 (width 35mm) DIN
Name Function
Power Supply Indication The LED is ON when power on the module
Module Name The model name of this special module
Expansion Port Link with other expansion module
Analogue input/output Used to connect with analogue input/output and peripheral
Module’s Structure 2
General Specifications 1

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
