Xinje XC3 Series User Manual

5 input specifications and wiring methods
5-3-3．The Input Wiring Of HSC
For the input wiring of pulse, it differs according to PLC’s model and counter’s model. Below,
we show several typical wiring method (take XC3-48 PLC as the example):
Increment Mode 1
Pulse+Direction
Mode
2
AB Phase Mode 3

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
