Xinje XC3 Series User Manual

① For Expansion E
② Analogue Input 4AD：4CH analogue input
8AD：8CH analogue input
③
Analogue Output 2DA：2CH analogue output
4DA：4CH analogue output
④ PT100 Temperature 6PT：6CH PT100
⑤
K type thermocouple 6TCA：6CH thermocouple input (V3.1or above)
⑥ P、I、D tune P：with PID tune
- XC-E8X8YR XC-E8X8YT 16 8 8
XC-E16X - - 16 16 -
- XC-E16YR XC-E16YT 16 - 16
- XC-E16X16YR XC-E16X16YT 32 16 16
XC-E32X - - 32 32 -
N
- XC-E32YR - 32 - 32
XC-E8PX - - 8 8 -
- XC-E8YR XC-E8YT 8 - 8
- XC-E8PX8YR XC-E8PX8YT 16 8 8
XC-E16PX - - 16 16 -
- XC-E16YR XC-E16YT 16 - 16
- XC-E16PX16YR XC-E16PX16YT 32 16 16
XC-E32PX - - 32 32 -
P
N
P
- XC-E32YR - 32 - 32
Analogue&Temperature
Expansion
2
Analogue、Temperature model name Principle:
XC－E 4AD 4DA 6PT 6TCA – P
① ② ③ ④ ⑤ ⑥

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
