Xinje XC3 Series User Manual

Blank：without PID tune
l Analogue、temperature modules list:
①
Analogue Input 4AD：4CH analogue input
8AD：8CH analogue input
② PT100 Temperature 6PT：6CH PT100 temperature Testing
③ K Type thermocouple 6TC：6CH thermocouple testing
④
P、I、D Tune P：with PID tune
Blank：without PID tune
⑤ For BD card BD
l BD card list
Model Description
XC-E8AD 8CH analogue input
XC-E4AD 4CH analogue input
Analogue
Input
XC-E4AD2DA 4CH analogue input, 2CH analogue output
XC-E2DA 2CH analogue output
Analogue
Output
XC-E4DA 4CH analogue output
XC-E6PT-P 6CH PT100 testing with PID tune
XC-E6TCA-P 6CH K type thermocouple testing, each channel's PID tune separately
XC-E3AD4PT2DA 3CH analogue input, 4CH PT100 testing, 2CH analogue output
Temperature
Testing
XC-E2AD2PT2DA 2CH analogue input, 2CH PT100 testing, 2CH analogue output
The BD card name principle:
XC－4AD 6PT 6TC– P– BD
① ② ③ ④ ⑤
BD Card
3

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
