Xinje XC3 Series User Manual

8 expansion devices
0V
24V
VO2
C3AO2C2
VO0 VO1
C0 AO0 C1 AO1
VO3
AO3
CH NAME SIGNAL CH NAME SIGNAL
AO0 Current analogue output AO1 C
urrent analogue output
VO0 Voltage analogue output VO1 Voltage analogue output
CH0
C0 COM of CH0
CH1
C1 COM of CH1
AO2 Current analogue output AO3 C
urrent analogue output
VO2 Voltage analogue output VO3 Voltage analogue output
CH2
C2 COM of CH2
CH3
C3 COM of CH3
24V +24V power supply
Items Voltage Output Current Output
Analogue Output
Range
DC0～5V、0～10V
(external load resistor
2KΩ~1MΩ)
DC0～20mA、4～20mA
(external load resistor less than 500Ω)
Digital Input Range
12 bits binary
Distinguish Ratio 1/1023(10Bit); the convert data is stored in PLC in form of Hex. (12Bit)
Integral Precision 0.8%
Convert Speed 3ms/CH
Power Supply DC24V±10%，100mA
l 4CH analogue output: voltage and current input selectable; Voltage input range is 0～5V、
0～10V selectable, current input range is 0～20mA、4～20mA selectable;
l 10 bits high precision analogue output;
l As the special module, 7pcs XC-E4DA can be connected to one XC series PLC main unit;
Terminal 3
Specification 2

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
