Xinje XC3 Series User Manual

※1：Generally, clock and RS485 are standard configuration on communication port. But some models are not
included. Please refer to Appendix 4.
l XC1 Series Model List
Model
AC Power Supply DC Power Supply
Relay output
Transistor
output
Relay output
Transistor
output
Input points
(DC24V)
Output
points
(R，T)
XC1-10R-E XC1-10T-E XC1-10R-C XC1-10T-C 5 5
XC1-16R-E XC1-16T-E XC1-16R-C XC1-16T-C 8 8
XC1-24R-E XC1-24T-E XC1-24R-C XC1-24T-C 12 12
N
P
N
XC1-32R-E
XC1-32T-E XC1-32R-C XC1-32T-C 16 16
XC1-10PR-E XC1-10PT-E XC1-10PR-C XC1-10PT-C 5 5
XC1-16PR-E XC1-16PT-E XC1-16PR-C XC1-16PT-C 8 8
XC1-24PR-E XC1-24PT-E XC1-24PR-C XC1-24PT-C 12 12
P
N
P
XC1-32PR-E XC1-32PT-E XC1-32PR-C XC1-32PT-C 16 16
l XC2 Series Model List
Model
AC
Power Supply
DC
Power Supply
Relay output
Relay
output
Transistor
output
R/T Type
Input
points
(DC24V)
Output
points
(R，T)
XC2-14R-E XC2-14T-E XC2-14RT-E XC2-14R-C XC2-14T-C XC2-14RT-C 8 6
XC2-16R-E XC2-16T-E XC2-16RT-E XC2-16R-C XC2-16T-C XC2-16RT-C 8 8
XC2-24R-E XC2-24T-E XC2-24RT-E XC2-24R-C XC2-24T-C XC2-24RT-C 14 10
XC2-32R-E XC2-32T-E XC2-32RT-E XC2-32R-C XC2-32T-C XC2-32RT-C 18 14
XC2-48R-E XC2-48T-E XC2-48RT-E XC2-48R-C XC2-48T-C XC2-48RT-C 28 20
N
P
N
XC2-60R-E
XC2-60T-E XC2-60RT-E XC2-60R-C XC2-60T-C XC2-60RT-C 36 24
XC2-14PR-E XC2-14PT-E XC2-14PRT-E XC2-14PR-C XC2-14PT-C XC2-14PRT-C 8 6
XC2-16PR-E XC2-16PT-E XC2-16PRT-E XC2-16PR-C XC2-16PT-C XC2-16PRT-C 8 8
XC2-24PR-E XC2-24PT-E XC2-24PRT-E XC2-24PR-C XC2-24PT-C XC2-24PRT-C 14 10
XC2-32PR-E XC2-32PT-E XC2-32PRT-E XC2-32PR-C XC2-32PT-C XC2-32PRT-C 18 14
P
N
P
XC2-48PR-E XC2-48PT-E XC2-48PRT-E XC2-48PR-C XC2-48PT-C XC2-48PRT-C 28 20
CPU Units List
2

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
