Xinje XC3 Series User Manual

8 expansion devices
1※ : When no signal input, the channel’s data is 4095;
2※ : According to the actual requirements, connect with the thermo-resistors;
0V
24V
TC1+
TCO- TC1- TC2- TC3- TC4- TC5-
TC5+TC4+TC3+TC2+_TC0+
Y1 .
Y5Y3COM2COM1
COM0
Y0 Y2 Y4
CH NAME SIGNAL CH NAME SIGNAL
TC0+ CH0 temperature input＋ CH1 TC1+ CH1 temperature input＋
CH0
TC0- CH0 temperature input－ TC1- CH1 temperature input－
CH2 TC2+ CH2 temperature input＋ CH3 TC3+ CH3 temperature input＋
TC2- CH2 temperature input－ TC3- CH3 temperature input－
CH4 TC4+ CH4 temperature input＋ CH5 TC5+ CH5 temperature input＋
TC4- CH4 temperature input－ TC5- CH5 temperature input－
Y0~Y5
Output Channel Y0～Y5
Analogue Output: in the form of digital type, the range is 0~4095
Digital Output: in the form of occupy ratio, Y output in the activate time
24V +24V power supply
－
0V COM of power supply
Items Specifications
Analogue Input Signal K、S、E、N、J、T、R type thermocouples
Temperature testing range 0℃～1000℃
Digital Output range 0～4095, without sign 12 bits, decimal
Control precision 0.1℃
Distinguish Ratio 0.1℃
Integral Precision 0.1℃
Convert Speed 20ms/CH
Power Supply DC24V±10%，50mA
Terminal Arrangement 3

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
