Xinje XC3 Series User Manual

9 change the soft components
Continue to click it, the replacement window will pop up:
As in the above graphs, we need only 5 minutes replace I/O terminals. This method avoids us
to modify the program, change PLC etc.
※1: after modification, make sure to restart PLC
In the pop-up window,
click X2, disable the
faulty terminal X2
In the pop-up window,
click X4, replace the
faulty terminal X2 with
X4
Click “Replace”, the
status table will change,
the original X2 changes
to be , which
means X2 has been
disabled.

Xinje XC3 Series Specifications

General

Series	XC3
Type	PLC
Communication Ports	RS232, RS485
Power Supply	24V DC
CPU Type	32-bit
Programming Software	XCP Pro
Operating Temperature	55°C
Analog Inputs	Optional, depends on expansion modules
Analog Outputs	Optional, depends on expansion modules
