W
ireless Access Point
516
Internal RADIUS
Administrat
or Account and Password
Management
Primary Server
None
Primary Port
1813
Primary Secret
null (no secret)
Secondary Server
None
Secondary Port
1813
Secondary Secret
null (no secret)
Setting
Default V
alue
Enabled
No
The user database is cleared upon r
e
set to the factory defaults. For
the
Internal RADIUS Server you have a maximum of 1,000 entries.
Setting
Default V
alue
ID
admin
Passwor
d
admin
Setting
Default V
alue
SSH
On
SSH timeout
300 seconds
Setting
Default V
alue
541
543
