ForeSite SS Hardware24
Figure 4
Warning: The dual hub is for use only with the ForeSite SS Tablet System
(USB SPK). It allows connecon of two USB SPKs to the tablet.
Dual Sensor Pad Systems
Dual sensor pad systems include all the same components as listed
above for the single pad systems with the excepon of:
√ 1 addional Pressure Imaging Sensor Pad
√ 1 addional Sensor Pack (SPK)
√ 1 Dual USB Hub
The dual sensor pad system is connected as shown in Figure 4.
