Xylem FST User Manual

1. FST module
2. FST module cover
3. 21-pin connector
4. Satellite antenna
5. Cellular antenna
6. PCB assembly
7. Modem
8. Mounting bracket
2.4 Extra parts
Part number Item Description
Optional MJK flowmeter Connects with the PrimeGuard 2 and PV102P
control panel to measure the flow of the liquid
Optional Suction pressure transducer Connects with the PrimeGuard 2 and PV102P
control panel to measure the suction pressure
in psi
Optional Discharge pressure
transducer
Connects with the PrimeGuard 2 and PV102P
control panel to measure the discharge
pressure in psi
Optional Fuel level transducer Connects with the PrimeGuard 2 and PV102P
control panel to measure the fuel level in %
Optional Sump level transducer Connects with the PrimeGuard 2 and PV102P
control panel to measure the sump level in ft
Optional Vibration sensor Connects with the I/O extension cable to
measure the vibration
FSTWIREHARNESS Wiring harness for the FST
module
Connects the FST module and the control panel
FSTIOEXTCABLE I/O extension cable for the
FST module
Connects digital input and analog input
devices such as floats, flowmeters, transducers
to the FST module
4000174 Pigtail harness Connects with the PrimeGuard 2 control panel
GPFSTBRKT Mounting bracket Used to install the FST module on the pump
engine enclosure
2902829 Signal isolator Used to connect the flowmeter to the
PrimeGuard 2 and PV102P control panel
2 Product Description
8 FST Installation, Operation, and Maintenance Manual
