Transmitting data Multi 3630 IDS
100 ba77170e03 10/2017
Adjusting the set-
tings for the data
transmission
Starting the program
for the data
reception
Transmitting data
(options)
2. Set the same transmission data at the meter and PC:
 Baud rate: to be selected in the range 1200 ... 19200
 Set at the PC only:
– Handshake: RTS/CTS
– Parity: none
– Data bits: 8
– Stop bits: 1
3. On the PC, start the program for the data reception, e.g.:
 MultiLab Importer (see section 13.4)
 Terminal program
Data Control Operation / description
Current mea-
sured values
of all con-
nected sen-
sors
Manual  With <PRT>.
 Simultaneously with every manual
storing process (see section 12.1).
Automatic, at
intervals
 With <PRT_>.
Then you can set the transmission
interval
 Simultaneously with every automatic
storing process (see section 12.2).
Stored mea-
sured values
Manual  Displayed dataset with <PRT> after
calling up from the storage.
 All datasets with the function, Output to
RS232/USB
(menu Data storage / Manual data
storage or Automatic data storage).
For details, see section 12.3.1.
Calibration
records
Manual  Displayed calibration record with
<PRT>
 All calibration records with Output to
RS232/USB
(menu Calibration / Calibration data
storage)
Automatic  At the end of a calibration procedure
