Xylem wtw Multi 3630 IDS - Measured Value Display; Menus and Dialogs

Operation Multi 3630 IDS
24 ba77170e03 10/2017
4.5.2 Measured value display
In the measured value display, you can
 use <><> to select one of several connected sensors. The selected
sensor is displayed with a colored background.
The following actions / menus refer to the selected sensor
 open the menu for calibration and measurement settings with <ENTER>
(short
keystroke)
 open the Storage & config menu with the sensor-independent settings with
<ENTER_> (long
pressure (approx. 2 s) on <ENTER>).
 change the display in the selected measuring screen (e. g. pH <-> mV) by
pressing <M>.
4.5.3 Menus and dialogs
The menus for settings and dialogs in procedures contain further subelements.
The selection is done with the <><> keys. The current selection is dis-
played with a frame.
 Submenus
The name of the submenu is displayed at the upper edge of the frame. Sub-
menus are opened by confirming with <ENTER>. Example:
 Settings
Settings are indicated by a colon. The current setting is displayed on the
right-hand side. The setting mode is opened with <ENTER>. Subsequently,
Storing in
memory
The meter stores measuring data automatically or manually
Transmit-
ting data
The meter transmits measuring data and calibration records
to a USB-B interface automatically or manually.
Setting The system menu or a sensor menu with submenus, set-
tings and functions is displayed
Operating
mode
Explanation
General
Interface
Clock function
Service information
Reset
System
30.09.2015 08:00
