Page 132 FT-2000D OPERATING MANUAL
General
Rx Frequency Range: 30 kHz - 60 MHz (operating)
160 - 6 m (specified performance, Amateur bands only)
Tx Frequency Ranges: 160 - 6 m (Amateur bands only)
Frequency Stability: ±0.5 ppm (after 1 minute @+77 °F [+25 °C])
±1.0 ppm (after 1 minute @+14 °F ~ +122 °F [–10 °C ~ +50 °C])
Operating Temperature Range: 14 °F ~ +122 °F (–10 °C ~ +50 °C)
Emission Modes: A1A (CW), A3E (AM), J3E (LSB, USB), F3E (FM),
F1B (RTTY), F1D (PACKET), F2D (PACKET)
Frequency Steps: 1/5/10 Hz (SSB,CW, & AM), 100 Hz (FM)
Antenna Impedance: 50 Ohms, unbalanced
16.7 - 150 Ohms, unbalanced (Tuner ON, 160 - 10 m Amateur bands)
25 - 100 Ohms, unbalanced (Tuner ON, 6 m Amateur band)
Power Consumption: Rx (no signal) 70 VA
Rx (signal present) 80 VA
Tx (200 W) 720 VA
Supply Voltage: AC: 90 VAC - 132 VAC or 180 VAC- 264 VAC
Dimensions (WxHxD): 16.1” x 5.3” x 13.8” (410 x 135 x 350 mm)
Weight (approx.): 34.1 lbs (15.5 kg)
Transmitter
Power Output: 10 - 200 watts
10 - 75 watts (Class-A, SSB)
5 - 50 watts (AM carrier)
Modulation Types: J3E (SSB): Balanced,
A3E (AM): Low-Level (Early Stage),
F3E (FM): Variable Reactance
Maximum FM Deviation: ±5.0 kHz/±2.5 kHz
Harmonic Radiation: Better than –60 dB
SSB Carrier Suppression: At least 60 dB below peak output
Undesired Sideband Suppression: At least 60 dB below peak output
Audio Response (SSB): Not more than –6 dB from 300 to 2700 Hz
3rd-order IMD: –31 dB @14 MHz, 200 watts PEP
–45 dB @14 MHz, 75 watts Class-A
Microphone Impedance: 600 Ohms (200 to 10 kOhms)
SPECIFICATIONS
FP-2000 Power Supply
Input Voltage: 90 VAC - 264 VAC, 50/60 Hz (Universal)
Output Voltage: 50 VDC , 13.8 VDC
Maximum Power Consumption (approx.): 720 VA
Maximum Output Current: 50 V: 12 A, 13.8 V: 6 A
Case Size (WxHxD): 3.9” x 5.3” x 13.8” (100 x 135 x 350 mm)
Weight (approx.): 7.9 lb (3.6 kg)
