Yale Assure Lock 2 Touch User Manual

22
P/N YRD450-KF-F Rev A
1. Take off DoorSense cover.
2. Push the magnet out of the housing.
3. Expose the adhesive on the magnet cap by removing the blue backing.
4. Press the magnet onto the cap so that the notches interlock.
5. Determine mounting location on the door frame. The distance from the
center of the strike plate to the center of the DoorSense should be 2”,
making the DoorSense in line with the logo on the battery cover of the lock.
6. Mark a hole that’s horizontally centered on the door frame and is 5/8” in
diameter.
7. Drill a 1/2” deep hole where marked.
8. Insert DoorSense into the hole.
Note: If it is too snug to push in by hand, protect the frame with a piece of scrap wood
and use light blows with a hammer or mallet. If it is too loose, try wrapping tape around
it so that it fits snugly.
1
3
4
5
8
67
2
2”
5/8”
1/2”
9c
DoorSense Flush Mount
Frame

Yale Assure Lock 2 Touch Specifications

General

Keypad Type	Touchscreen
Power Source	4 AA Batteries
Backlit Keypad	Yes
Door Thickness	1-3/8" to 2-1/4"
Connectivity	Bluetooth
Compatibility	Amazon Alexa, Google Assistant, Apple HomeKit
Auto-Lock	Yes
Voice Assistance	Amazon Alexa, Google Assistant
Battery Life	Up to 1 year
Operating Temperature	-40°F to 140°F (-40°C to 60°C)
Remote Access	Yes
Guest Access	Yes
Security	BHMA Grade 2 Certified
Finish	Satin Nickel
