ASSEMBLE
1. Install control handle card in the upper half of con-
trol handle. See Figure 16.
NOTE: When inserting knobs, make sure that flange
on one of the butterfly knobs inserts between spring
on handle (9).
2. Slide shaft and butterfly knob into control handle
card. Be careful not to rotate the shaft inside the
control handle card.
3. Connect the switches and wire harness connec-
tors.
4. Install the remaining butterfly knob. Apply Loctite
242™ to the screw attaching the butterfly knob
onto the upper half of the handle and tighten
screw. Tighten screw to 1 N•m (9 lbf in).
5. Lubricate friction points on the butterfly knobs with
silicone spray lubricant.
NOTE: It may not have been necessary to remove
the lower half of the control handle cover. If the cover
(lower half) is already installed to the control handle
shaft, skip to Step 7.
6. Install lower half of control handle cover to control
handle shaft and secure with two capscrews. Tor-
que to 27 N•m (20 lbf ft).
7. Plug handle wiring harness into control handle
card.
CAUTION
DO NOT force the upper half onto the lower half
as this will cause damage to the retaining hooks
of the upper half.
8. To install upper half of handle onto the lower half:
a. Tip the upper half up and align the hooks under
the auto-reverse switch.
b. Lower the upper half onto the lower half.
9. Install capscrews to retain upper half of control
handle to lower half.
10. Connect battery cable and test control handle op-
eration.
2200 YRM 1007 Control Handle
23
