Assigning Faders & On Buttons 195
01V—Owner’s Manual
Fader Assignments
Faders 1 through 16 and master can be assigned to the following parameters.
Parameter Channel
NO ASSIGN — —
FADER
CHANNEL
CH1–12, CH13-14, CH15-16, CH17–24,
RETURN1, RETURN2
MASTER AUX1–4, BUS1–4, EFFECT1, EFFECT2, ST OUT
AUX1 SEND, AUX2 SEND
CH1–12, CH13-14, CH15-16, CH17–24,
RETURN1, RETURN2
AUX3 SEND, AUX4 SEND
CH1–12, CH13-14, CH15-16, RETURN1,
RETURN2
EFF1 SEND
CH1–12, CH13-14, CH15-16, CH17–24,
RETURN2
EFF2 SEND
CH1–12, CH13-14, CH15-16, CH17–24,
RETURN1
DELAY
TIME
CH1–12, CH13-14, CH15-16, ST OUT L, ST
OUT R, OMNI1–4
MIX
FB GAIN
EQ (F, G, Q)
F LOW
CH1–12, CH13-14, CH15-16, CH17–24,
RETURN1, RETURN2, AUX1–4, ST OUT
G LOW
Q LOW
F L-MID
CH1–12, CH13-14, CH15-16, RETURN1,
RETURN2, AUX1–4, ST OUT
G L-MID
Q L-MID
F H-MID
CH1–12, CH13-14, CH15-16, RETURN1,
RETURN2, AUX1–4, ST OUT
G H-MID
Q H-MID
F HIGH
CH1–12, CH13-14, CH15-16, CH17–24,
RETURN1, RETURN2, AUX1–4, ST OUT
G HIGH
Q HIGH
ATT CH1–12, CH13-14, CH15-16, CH17–24
DYNAMICS
RATIO
CH1–12, CH13-14, CH15-16, AUX1–4, ST OUT
KNEE/HOLD
THRESHOLD
ATTACK
G/RANGE
REL/DECAY
EFFECT
EFFECT1
PARAM1–19
EFFECT2
PAN
CHANNEL
CH1–24, RETURN1 L, RETURN1 R, RETURN2 L,
RETURN2 R
AUX1, 2
AUX3, 4
CH1–16, RETURN1 L, RETURN1 R, RETURN2 L,
RETURN2 R
BUS TO ST BUS1–4
BALANCE ST OUT
