Setting Effects Returns Levels 131
01V—Owner’s Manual
Setting Effects Returns Levels
Effects return levels are controlled using the effects return
rotary controls.
To adjust the level of an effects return, press the [HOME] but-
ton, and then use the rotary controls.
Rotary control operation depends on the selected Fader mode.
See “Faders (plus Return Rotary Controls)” on page 35 for
more information. The selected fader mode is shown on the
display. See “Display” on page 28 for more information.
Panning Effects Returns
Effects return panpots are used to pan signals between the left and right channels of the
stereo out, and the odd and even bus outs. See “Panning Input Channels” on page 47
for more information.
Routing Effects Returns
Effects returns can be routed to the four buses and stereo out. See “Routing Input Chan-
nels” on page 49 for more information.
Monitoring Effects Returns
Effects returns can be monitored using the monitor out or phones. See “Monitor Setup”
on page 78 for more information.
Effects Returns & Aux Sends
Signals from effects returns 1 and 2 can be sent to aux sends 1 through 4. Effects return
sends can be configured as either pre-fader or post-fader sends. When aux sends are
paired, aux send panpots become available on each effects return. See “Aux Sends” on
page 93 for more information.
1 RETURN 2
