Fader Modes 35
01V—Owner’s Manual
To turn on or off the AUX 1 send master, press the [AUX 1] button, and then use the
MASTER [ON] button.
To turn on or off the EFFECT 1 send master, press the [EFFECT 1] button, and then
use the MASTER [ON] button.
Faders (plus Return Rotary Controls)
The faders are used to adjust channel levels.
Faders 1 through 16 and master can be assigned to various internal parameters on
REMOTE page 1, or used as MIDI controllers on REMOTE page 3. See “Assigning Fad-
ers & On Buttons” on page 194 and “User Defined MIDI Controllers” on page 238 for
more information.
Input Channel Level Examples
To adjust the level of input channel 3, press the [HOME] button, and then operate fader
3.
To adjust the level of input channel 13/14, press the [HOME] button, and then operate
fader 13/14.
To adjust the level of input channel 20, press the [OPTION I/O] button, and then oper-
ate fader 20.
Input Channel Aux Send Examples
To adjust the aux 1 send level of input channel 3, press the [AUX 1] button, and then
operate fader 3.
*1. Effects return 1 cannot be fed to effect send 1
*2. Effects return 2 cannot be fed to effect send 2
*3. CH17–20 with four-input Option I/O cards.
Fader Mode
Fader Rotary Control
1–8
[17–24]
9–12 13/14
15/16
STEREO
[MASTER]
RETURN 1/2
HOME
CH 1–16 level
STEREO
master level
RETURN 1/2 levels
AUX 1
CH 1–16 AUX 1 send level
AUX 1
master level
RETURN 1/2 AUX
1 send levels
AUX 2
CH 1–16 AUX 2 send level
AUX 2
master level
RETURN 1/2 AUX
2 send levels
AUX 3
CH 1–16 AUX 3 send level
AUX 3
master level
RETURN 1/2 AUX
3 send levels
AUX 4
CH 1–16 AUX 4 send level
AUX 4
master level
RETURN 1/2 AUX
4 send levels
EFFECT 1
CH 1–16 EFFECT 1 send level
EFFECT 1
master level
RETURN 1 level
*1
RETURN 2 EFFECT
1 send level
EFFECT 2
CH 1–16 EFFECT 2 send level
EFFECT 2
master level
*2
RETURN 1 EFFECT
2 send level
RETURN 2 level
OPTION I/O
CH 17–24
*3
level
——
STEREO
master level
RETURN 1/2 levels
REMOTE 1
Assigned internal parameters —
REMOTE 2
—
REMOTE 3
User defined MIDI controllers —
