34 Chapter 4—Getting Around the User Interface
01V—Owner’s Manual
ON Buttons
The [ON] buttons are used to turn channels on or off. They work with the following
channels:
•
CH1 through CH24—Input channels 1 through 24
•
ST—Stereo output
•
RTN1, RTN2—Effects returns 1 and 2
•
AUX1 through AUX4—Aux sends 1 through 4
•
EFF1, EFF2—Effects sends 1 and 2
The bus outs can be turned on or off on PAN/ROUT page 4.
On buttons 1 through 16 and master can be assigned to various internal parameters on
REMOTE page 1, or used as MIDI controllers on REMOTE page 3. See “Assigning Fad-
ers & On Buttons” on page 194 and “User Defined MIDI Controllers” on page 238 for
more information.
Input Channel [ON] button Examples
To turn on or off input channel 3, press the [HOME] button, and then press [ON] but-
ton 3. (If a fader mode other than Option I/O or Remote is selected, it’s not necessary
to press the [HOME] button.)
To turn on or off input channels 13/14, press the [HOME] button, and then press [ON]
button 13/14. (If a fader mode other than Option I/O or Remote is selected, it’s not nec-
essary to press the [HOME] button.)
To turn on or off input channel 20, press the [OPTION I/O] button, and then press
[ON] button 20.
Master [ON] Button Examples
To turn on or off the stereo output, press the [HOME] button, and then use the MAS-
TER [ON] button.
*1. CH17–20 with four-input Option I/O cards.
Fader Mode
ON button
1–8
[17–24]
9–12 13/14
15/16
STEREO
[MASTER]
RETURN 1/2
HOME
CH 1–16 On/Off
STEREO OUT
On/Off
RETURN 1/2
On/Off
AUX 1
AUX 1
master On/Off
AUX 2
AUX 2
master On/Off
AUX 3
AUX 3
master On/Off
AUX 4
AUX 4
master On/Off
EFFECT 1
EFFECT 1
master On/Off
EFFECT 2
EFFECT 2
master On/Off
OPTION I/O
CH 17–24
*1
On/Off
——
STEREO OUT
On/Off
REMOTE 1
Assigned internal parameters —
REMOTE 2
MMC (1–6) —
REMOTE 3
User defined MIDI controllers —
