Yamaha 01V - EQ Specs; Bypassing the EQ; Resetting the EQ

66 Chapter 6—EQ
01V—Owner’s Manual
EQ Specs
The following table contains the EQ specs.
Bypassing the EQ
The selected channel’s EQ can be turned on or off using the EQ ON switch on
the EQ page (OPTION page 2 for channels 17 through 24), or the [ENTER]
button. While the EQ page is displayed, the [ENTER] button turns the EQ on
or off regardless of the cursor position.
Resetting the EQ
To reset all the EQ parameters on the selected channel to their initial values, press the
[HIGH] and [LOW] buttons simultaneously.
The following table contains the initial EQ values.
1. Four-band EQs only (low and high bands only on input channels 17 through 24).
2. When the low and high EQ bands are configured as HPF and LPF, their gain controls
function as filter on and off switches.
1. Four-band EQs only (low and high bands only on input channels 17 through 24).
Low
Lo-Mid
1
Hi-Mid
1
High
Gain (G)
–18.0 dB to +18.0 dB (0.5 dB steps)
2
Frequency (F)
21 Hz–20.1 kHz (1/12 octave steps, 120 steps)
Q
HPF, 10.0–0.10
(41 steps),
L.SHELF
10.0–0.10 (41 steps)
LPF, 10.0–0.10
(41 steps),
H.SHELF
Low
Lo-Mid
1
Hi-Mid
1
High
Gain (G)
0 dB 0 dB 0 dB 0 dB
Frequency (F)
125 Hz 1.00 kHz 4.00 kHz 10.0 kHz
Q
L.SHELF 0.70 0.70 H.SHELF
ENTER
