EQ 267
01V—Owner’s Manual
EQ
*1. 4-band EQs only (low and high bands only on input channels 17 through 24).
*2. When the low and high EQ bands are configured as HPF and LPF, their gain controls function
as filter on and off switches.
Low
Lo-Mid
*1
Hi-Mid
1
High
Gain (G)
–18.0 dB to +18.0 dB (0.5 dB steps)
*2
Frequency (F)
21 Hz–20.1 kHz (1/12 octave steps, 120 steps)
Q
HPF, 10.0–0.10
(41 steps),
L.SHELF
10.0–0.10 (41 steps)
LPF, 10.0–0.10
(41 steps),
H.SHELF
